In-situ Laser Gas Analyzers

Classification:

Product Description:

The iLAS series in-situ laser gas analyzer adopts the principle of Tunable Diode Laser Absorption Spectroscopy (TDLAS) to measure the concentration of specific gases in the process gas composition, including NH3, HCL, HF, H2S, CH4, O2, CO, CO2, etc. CO2, etc. The gas analyzer is characterized by high sensitivity, fast response time, no background gas interference, non-contact optical measurement, etc. It can be used in many industrial fields for gas emission monitoring, process control and other scenarios, providing a reliable guarantee for real-time and accurate reflection of gas concentration changes.
Inquiry

Product Details


iLASAdvantages of in-situ measurement methods

• Direct analysis of the process gas, no sampling loss change

• Measure the average concentration of the pipeline section, closer to the real working conditions

• Real-time response, providing real gas concentration changes

• Non-contact optical measurement, suitable for extreme conditions such as high temperature, high pressure and dust

• Customized development for the measurement process



Typical applications for in-situ measurements

• Blast Furnace Gas Safety Monitoring

• Converter Gas Recovery

• Hot blast furnace flue gas monitoring

• Heating Furnace Combustion Optimization

• Reactor Oxygen Analysis





Performance Parameters

Model

iLAS-700-O2

iLAS-700-CO

iLAS-700-CO2

iLAS-700-CH4

Form

Single-ended reflection

Single-ended reflection

Single-ended reflection

Single-ended reflection

Gas

O2

CO

CO2

CH4

Measurement low limit

0.01%

0.01%

0.01%

0.01%

Maximum range

0-99.99%

0-99.99%

0-99.99%

0-99.99%



Functional parameters

Power supply

AC220V/DC24V

Analog Inputs

2-channel 4-20mA

Analog Output

2-way 4-20mA,max load 750Ω

Operation interface

Magnetically controlled graphic interaction

Relay Output

3-way (24V/1A)

Digital Output

RS485,support MODBUS RTU protocol



Environmental parameters

Light length

≤15m

Sample gas temperature

≤800℃

Sample gas pressure

Atmospheric pressure ±5kPa

Ambient temperature

-30-55℃

Sample gas humidity Condensate free water

Ambient Humidity

≤90%RH

Explosion-proof grade

ExdⅡ CT6

Protection level

IP66

Blowdown air

0.4-0.6MPa,Nitrogen source



Note: 1. Special gases such as H2O, C2H6, HCL, HF, HCN, etc. are available for customization; 2. The range can be customized according to the application conditions; 3. The actual optical range is designed according to the installation pipe size conditions
